HandyTone-486 User Manual Grandstream Networks, Inc.
25
Disable Call-
Waiting:
No Yes
Send DTMF:
in-audio via RTP (RFC2833) via SIP INFO
DTMF Payload Type:
101
Send Flash Event:
No Yes (Flash will be sent as a DTMF event if set to Yes)
FXS Impedance:
current setting is " 600 Ohm (North America)"
Caller ID Scheme:
current setting is " Bellcore"
Onhook Voltage:
current setting is " 36V"
Polarity Reversal:
No Yes (reverse polarity upon call establishment and termination)
NTP Server:
time.nist.gov
(URI or IP address)
Send Anonymous:
No Yes (caller ID will be blocked if set to Yes)
Lock keypad update:
No Yes (configuration update via keypad is disabled if set to Yes)
Special Feature:
current setting is "Standard"
WAN Side HTTP
Access:
No Yes (WAN side access to http server will be rejected if set to No)
PSTN Access Code:
(key pattern to use the PSTN line, default is "*00")
Syslog Server:
Syslog Level:
current setting is "NONE"
Update
Cancel
Reboot
All Rights Reserved Grandstream Networks, Inc. 2005
Admin Password
Administrator password. Only administrator can configure the “Advanced Settings” page.
Password field is purposely blanked for security reason after clicking update and saved. The
maximum password length is 25 characters.
SIP Server
IP address or Domain name provided by VoIP service provider
Outbound Proxy
IP address or Domain name of Outbound Proxy, or Media Gateway, or Session Border
Controller. Used by ATA for firewall or NAT penetration in different network environment. If
symmetric NAT is detected, STU
will not work and ONLY outbound proxy will provide
solution for it.
SIP User ID
User account information, provided by VoIP service provider (ITSP), usually has the form of
digit similar to phone number or actually a phone number
Authenticate ID
ID used for authentication, usually same as SIP user ID, but could be different and decided by
ITSP.
