ENWW Configuring for LPD Printing 51
c. Select and enable Other Network File and Print
Services.
d. Click Details, and verify that Print Services for Unix is
enabled. If not, enable it.
e. Click Okay, and then Next.
2. Windows 2000: Open the Printers folder (from the Desktop,
click Start, Settings, and Printers).
Server 2003: Open the Printers and Faxes folder (from the
Desktop, click Start, Printers and Faxes).
3. Double-click Add Printer. From the Add Printer Wizard
welcome screen, click Next.
4. Select Local printer, and disable automatic detection for Plug
and Play printer installation. Click Next.
5. Choose Create a new port, and select LPR Port. Click Next.
6. In the Add LPR compatible printer window:
■ Enter the DNS name or IP address of the HP Jetdirect print
server.
■ Enter (in lower case) raw, text, or auto for the name of the
printer or print queue on the HP Jetdirect print server.
Then click OK.
Note The HP Jetdirect print server treats text files as
unformatted text or ASCII files. Files that are raw
are formatted files in PCL, PostScript, or HP-GL/2
printer languages.
For HP Jetdirect external print servers with three
ports, use raw1, raw2, raw3, text1, text2, text3
or auto1, auto2, auto3 to specify the port.
7. Select the Manufacturer and Printer model. (If necessary, click
Have Disk and follow the instructions to install the printer
driver.) Click Next.
8. Choose to keep the existing driver, if prompted. Click Next.
9. Enter a printer name, and choose whether this printer will be
the default printer. Click Next.
