72 HP Jetdirect Configuration Page Messages ENWW
LAN
ERROR-CONTROLLER
CHIP
Check the network connections. If the connections are
intact, run the power-on self-test: turn the printer off, then
on again. If the error persists, replace the HP
Jetdirect
print server.
LAN ERROR-EXTERNAL
LOOPBACK
The HP Jetdirect print server is incorrectly connected to
your network or is defective. Make sure your HP
Jetdirect
print server is correctly attached to your network. In
addition, check the cabling and connectors.
LAN ERROR-INFINITE
DEFERRAL
There is a network congestion problem. Check network
cables.
Note: If the print server is not connected to the network,
this error cannot occur.
LAN ERROR-INTERNAL
LOOPBACK
Check all network connections.
LAN ERROR-LOSS OF
CARRIER
Check the network connections. If the connections are
intact, run the power-on self-test: turn the print server off,
then on again. If the error persists, replace the
HP
Jetdirect print server.
LAN ERROR-NO
LINKBEAT
This message is displayed if Link Beat is not sensed.
Check the network cable, and verify that the
concentrator/hub is providing Link Beat.
LAN ERROR-NO SQE Check the network connections. If the connections are
intact, run the power-on self-test: turn the print server off,
then on again. If the error persists, replace the
HP
Jetdirect print server.
LAN ERROR-RECEIVER
OFF
There may be a problem with your network cabling or the
HP
Jetdirect print server. Check the cabling and
connectors on your Ethernet network. If you cannot find a
problem with your network cabling, run the power-on
self-test: turn the print server off, then on again. If the error
persists after the printer is turned on again, there is a
problem with the HP
Jetdirect print server.
LAN ERROR-REMOVE
RECEIVE
Run the power-on self-test: turn the print server off, then
on again. If this message reappears on the resulting
configuration page, you may have a problem with one of
the HP
Jetdirect print servers on your network. Check all
the HP
Jetdirect print servers on the network for proper
operation.
LAN ERROR-RETRY
FAULTS
There is a problem with your network cabling or external
network configuration. Check the network cables and
connections. Verify operation of the hub or switch port.
Table 7.2 General HP Jetdirect Messages (4 of 10)
Message Description
