COMMAND1 COMMAND2 DATA1 DATA2 DATA3
25. Tile ID Set d i 00H -19H
26. Natural Mode (In Tile mode) d j 00H -01H
27. Elapsed time return d l FFH
28. Temperature value d n FFH
29. Lamp fault check d p FFH
30. Auto Volume d u 00H -01H
31. Speaker d v 00H -01H
32. Time f a 00H -06H 00H - 17H 0 - 3BH
33. On Timer (On/Off Timer) On, Off f b 00H, FFH
34. Off Timer (On/Off Timer) On, Off f c 00H, FFH
35. On Timer (On/Off Timer) Time f d 00H -07H 00H - 17H 00 - 3BH
36. Off Timer (On/Off Timer) Time f e 00H -07H 00H - 17H 00 - 3BH
37. Sleep Time f f 00H -08H
38. Auto Sleep f g 00H -01H
39. Power On Delay f h 00H -64H
40. Language f i 00H -09H
41. DPM Select f j 00H -01H
42. Reset f k 00H -02H
43. S/W Version f z FFH
44. Input Select x b 20H -A0H
Transmission / Receiving Protocol
Transmission
[Command1][Command2][ ][Set ID][ ][Data][Cr]
*[Command 1]: First command. (k)
*[Command 2]: Second command.(a ~ u)
*[Set ID]: Set up the Set ID number of product.
range : 01H~63H. by setting '00H', server can control all products.
* In case of operating with more than 2 sets using set ID as '0' at the same time, it should not be
checked the ack message.
Because all sets will send the ack message, so it's impossible the check the whole ack messages.
*[DATA]: To transmit command data.
ENWW Transmission / Receiving Protocol 43
