Menu 0 Parameters D-5
Speed indication
0.10 Estimated motor speed
Estimated motor speed
RO Bi
±6000
RPM
0.10 indicates the value of motor speed that is
estimated from the following:
0.12 Post-ramp frequency reference
0.42 Motor – no. of poles
The value of 0.10 is applied to the analog output on
terminal 9 to indicate estimated speed.
Macro-number indication
0.31 Macro number
RO Uni
0 ~ 7
0.31 indicates the number of the macro
configuration that is currently in operation.
Miscellaneous
0.32 Serial comms. mode
RW Txt R P
ANSI 2
ANSI 4
OUtPUt
INPUt
ANSI 4
Use 0.32 to select the required serial
communications mode as follows:
ANSI 2 ANSI protocol, two-wire
ANSI 4 ANSI protocol, four-wire
0.33 Drive rated current (FLC)
RO Uni P
2.10 ~ 202
A
0.34 User security code
RW Uni S P
0 ~ 255 149
Use 0.34 to set up a User Security code.
Irrespective of the code number entered in 0.34, it
always indicates the default value 149. When 0.34
is actually set at 149, no User Security is applied.
See Setting-up User Security in Appendix B Security.
Keypad-reference monitoring
0.35 Keypad reference
RO Bi S P
± [0.02]
Hz
0.35 indicates the value of the frequency reference
when the Drive is operating in Keypad mode. The
reference is then controlled by the following control
keys (when the display is in Status mode):
The value is automatically saved when the Drive is
powered-down. At the next power-up, the Drive
ramps up to the frequency that applied before the
power-down.
Serial communications,
Parameter displayed after power-up
0.36 Serial comms. baud rate
RW Txt P
4800 (0)
9600 (1)
19200 (2)
2400 (3)
4800
(0)
baud
Use 0.36 to select the required baud rate for serial
communications when a Basic serial communications
large option module is fitted in the Drive.
0.37 Serial comms. address
RW Uni P
0.0 ~ 9.9 1.1 Group.Unit
Use 0.37 to select the required address for serial
communications when a Basic serial communications
large option module is fitted in the Drive.
Do not enter an address that contains a zero, since
this is used when addressing a group of Drives.
