Specications
Monitor
Specifications
MultiSync
®
LCD2070NX Notes
LCD Module Diagonal :
Viewable Image Size :
Native Resolution
(Pixel Count) :
20.1 inch
20.1 inch
1600 x1200
Active matrix; thin film transistor (TFT)
liquid crystal display (LCD); 0.255 mm
dot pitch; 250cd/m
2
white luminence;
700:1 contrast ratio, typical
Input Signal Video :
Sync :
ANALOG 0.7 Vp-p/75 Ohms
Separate sync. TTL Level Positive/Negative
Composite sync. Positive/Negative
Composite Sync on Green (0.3Vp-p nega-
tive and 0.7Vp-p positive)
Digital Input: DVI-D
Display Colors 16,777,216 Dependent on display card used.
Maximum Viewing
Angles
Left/Right :
Up/Down :
88°/88° (CR>10)
88°/88° (CR>10)
Synchronization
Range
Horizontal :
Vertical :
31.5 kHz to 91.1 kHz
56.0 Hz to 85.0 Hz
Automatically
Automatically
Resolutions
Supported
720 x 400*
1
:VGA text
640 x 480*
1
@ 60 Hz to 85 Hz
800 x 600*
1
@ 56 Hz to 85 Hz
832 x 624*
1
@ 75 Hz
1024 x 768*
1
@ 60 Hz to 85 Hz
1152 x 864*
1
@ 75 Hz
1152 x 870*
1
@ 75 Hz
1280 x 960 @*
1
@ 75 Hz
1280 x 1024*
1
@ 60 Hz to 85 H
z
1
600 x 1200 @ 60 Hz.........................
Some systems may not support all
modes listed.
NEC DISPLAY SOLUTIONS
cites recommended resolution
at 60 Hz for optimal display
performance.
Active Display Area Horizontal :
Vertical :
408 mm/16.1 inches
306 mm/12.0 inches
USB Hub I/P :
Port :
Load Current :
USB Specification Revision 2.0
Upstream 1
Downstream 4
Maximum 0.5A per port
Power Supply 100 – 240 V~ 50/60 Hz
Current Rating 1.25 - 0.70 A
Dimensions 442 mm (W) x 388.5-498.5 mm (H) x
220.0 mm (D)
17.4 inches (W) x 15.3-19.6 inches (H) x
8.7 inches (D)
Weight 8.6 kg
19.0 lbs
Environmental
Considerations
Operating Temperature :
Humidity :
Altitude :
Storage Temperature :
Humidity :
Altitude :
5°C to 35°C/41°F to 95°F
30% to 80%
0 to 12,000 Feet
-10°C to 60°C/14°F to 140°F
10% to 85%
0 to 40,000 Feet
*
1
Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each
dot on the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.
