34 Sun Fire X4150 Server Embedded Lights Out Manager Administration Guide • September 2007
Configuring the SSL Certificate
▼ To Configure the SSL Certificate
1. From the System Management Access submenu, click the SSL Certificate tab.
The SSL Certificate screen appears.
2. Select either Certificate or CSR from the drop-down list.
3. Fill in the required fields in the SSL Configuration section.
4. Click Generate to create the certificate.
5. Click Upload to bring the certificate into view.
Note – If no certificate has yet been assigned, follow the directions below to
generate a new CSR.
6. Follow the onscreen directions, and fill in the fields using the example as a
guide.
The example in
TABLE 4-1 represents the kind of information required.
7. Click Generate to create a new CSR.
Configuring SNMP
A series of screens allow you to set port, requests, and SNMP permission parameters
for the system you are logged in to.
TABLE 4-1 Example of Required SSL Information
Common Name (CN): localhost.localdomain
Organization Unit (OU): Your Name
Organization (O): Your Company Name
Country Code (C): U.S.A. (drop-down list of countries)
Locality (L): Your Location
State (S): Your State
E-mail Address (E): youradmin@localhost.localdomain
