Pin Assignment
Satellite U400/Satellite Pro U400/PORTEGE M800 Maintenance Manual 9
25 PCIE_TXP1 O 26 GND ---
27 GND --- 28 GND ---
29 GND --- 30 GND ---
CN16 Card Bus connector
P/N:DFHD68MR710 CONN SMD HEADER 68P 2R MR(P0.635,H5.5)
PIN No. Signal name I/O PIN No. Signal name I/O
1 GND --- 2 A_CAD0 I/O
3 A_CAD1 I/O 4 A_CAD3 I/O
5 A_CAD5 I/O 6 A_CAD7 I/O
7 A_CC/BE0# O 8 A_CAD9 I/O
9 A_CAD11 I/O 10 A_CAD12 I/O
11 A_CAD14 I/O 12 A_CC/BE1# O
13 A_CPAR I/O 14 A_CPERR# O
15 A_CGNT# I 16 A_CINT# O
17 AVCC --- 18 AVPP ---
19 A_CCLK I 20 A_CIRDY# O
21 A_CC/BE2# O 22 A_CAD18 I/O
23 A_CAD20 I/O 24 A_CAD21 I/O
25 A_CAD22 I/O 26 A_CAD23 I/O
27 A_CAD24 I/O 28 A_CAD25 I/O
29 A_CAD26 I/O 30 A_CAD27 I/O
31 A_CAD29 I/O 32 A_CRSVD/D2 I/O
33 A_CCLKRUN# I 34 GND ---
