Pin Assignment
34 Satellite U400/Satellite Pro U400/PORTEGE M800 Maintenance Manual
37 ODD_LED# O 38 +5V ---
39 +5V --- 40 +5V ---
41 +5V --- 42 +5V ---
43 GND --- 44 GND ---
45 GND --- 46 GND ---
47 GND --- 48 GND ---
49 NC --- 50 NC ---
51 GND --- 52 GND ---
CN37 Card Reader connector
P/N:DFHD42MS005 CONN SMD HEADER 42P 1R MS(P0.76,H5.6)
PIN No. Signal name I/O PIN
No.
Signal name I/O
1 GND --- 2 XD_CD# O
3 XD_R/B# I 4 XD_RE# I/O
5 XD_CE# I 6 XD_CLE O
7 XD_ALE I 8 XD_WE# I
9 GND I/O 10 GND ---
11 SD_D3 I/O 12 VCC_XD ---
13 XD_WPO# O 14 SD/MS_CLK_C ---
15 SD_CMD I 16 MS_D3/XD_D0 I/O
17 GND --- 18 MS_CD# ---
19 GND --- 20 MS_D2/XD_D1 I/O
