112 DocuPrint N4525 Network Laser Printer
Appendix C - Unique Printer Commands
Output Selection
The following table lists the output destinations supported by the printer along with the
PCL commands and PJL values to select them. (The values listed in the PJL column are the
settings associated with the PJL “OUTBIN” variable.)
Additional PJL Commands
The printer supports the standard set of PJL commands. The following table lists the PJL
extensions specific to the N4525 printer.
Output selection
Destination PCL 5e Command
1
1. The character following the “&” in the command string is the lower case character “L.”.
PJL (Used by PCL 5e and PCL 6)
Value for Variable “OUTBIN”
Automatic (no request) E
c
&l0G
Top (Face-down Bin) E
c
&l1G FACEDOWN or UPPER
Face-Up Bin E
c
&l2G FACEUP or LOWER or OPTIONALOUTPUTBIN1
Finisher Output Bin E
c
&l4G OPTIONALOUTPUTBIN2-11
Printer specific PJL commands
Function PJL Command Value Range
Start Secure Job @PJL XSECUREJOB n/a
Start Proof Job @PJL XPROOFJOB n/a
Job Password Assign @PJL SET XJOBPASSWORD = integer 4-digit string (0-7)
Select Collated Sets @PJL SET QTY = integer 0-999
Select an Emulation @PJL ENTER LANGUAGE= “language“ PostScript, PCL, PCLXL
Hard Disk Drive File
Delete
@PJL FSDELETE NAME = “pathname“
Hard Disk Drive File
Download
@PJL FSDOWNLOAD ...
Hard Disk Drive Initialize @PJL FSINIT VOLUME = “pathname“
Hard Disk Drive Directory
Create
@PJL FSMKDIR NAME = “pathname“
Line Termination @PJL SET XLINETERMINATION = value ON, OFF
Page Size Continue (Page
Policy)
@PJL SET PAGESIZECONTINUE = value IGNORESIZE,
IGNORETYPE,
IGNORETYPEANDSIZE
Edge to Edge @PJL SET XEDGETOEDGE = value ON, OFF
Tray Sequence @PJL SET XTRAYSEQUENCE = value TRAYMBF,
TRAYMBF1,
TRAYMBF12,
TRAY12,...
Novell PServer Name @PJL DEFAULT XPSERVERNAME =
“name“
0-47 characters
