iv 8e6 ThreaT analysis reporTer Quick sTarT Guide
View, Edit Gauge Components
To view gauge components for a specied gauge, highlight and double-click the gauge
name to populate the the elds to the right of the Gauge Groups list box.
The following gauge criteria can be edited:
Name: The displayed gauge name to be used in the interface can be modied by
making an entry in this eld.
Lower Limit: The default amount (“0” or zero) that will represent the lower end of the
gauge can be adjusted to accommodate the type of activity to be monitored on your
network.
Higher Limit: The default amount (“200”) that will represent the higher end of the
gauge can be adjusted to accommodate the type of activity to be monitored on your
network.
Gauge Components: To remove a gauge component, go to the Selected column
and click the checkmark in the checkbox corresponding to the component to be
removed.
NOTE: The settings saved in this step can be modied later in the interface.
Click NEXT > at the bottom right of the screen to go to Step 4.
•
•
•
•
