Alcatel OmniAccess 6000 LC-2G24FP Installation Instructions 1
Alcatel OmniAccess 6000 LC-2G24FP
Installation Instructions
The Alcatel 6000 SPOE Line Card (OAW-LC-2G24FP) has 24 Fast
Ethernet (FE) ports that support Serial and Power over Ethernet
(SPOE), and two Gigabit Ethernet Interface Card (GBIC) ports.
(SPOE and POE require 400W Power Supply Units,
OAW-600-PS400).
When connected directly to an IEEE 802.3af POE compatible
device, the port will provide power and data connectivity through
the same cable. For devices that support compatible serial wiring
or include an appropriate serial breakout adapter, such as the
Alcatel Wireless Access Point, the port will provide serial
connectivity as well as power and data.
Physical Description
Module Fastening Screws
These captive fastening screws are used for securing the module
in the switch chassis.
