Alcatel OmniAccess 6000 LC-2G24FP Installation Instructions 3
Module Indicator LEDs
Power LED
This LED lights green when the line card is properly installed and the system is
powered up.
Status LED
During operation, the Status LED provides the following information:
Access Point Status LEDs
Each LED represents the status of APs connected to a specific port on the
switch. During operation, the LEDs provide the following information:
The LED states show above are listed in order of precedence (highest to
lowest). If more than one AP is connected to the port, the state with the
highest precedence is displayed.
TABLE 3 Line Card Status LED
Status Description
Off The line card is powered off or initializing.
Green The line card is operating properly.
Amber The line card is being initialized.
Red The line card has failed.
TABLE 4 Line Card AP Status LED
Status Description
Red (solid) An AP on this port has failed (highest precedence).
Red (flashing) An air monitor on this port has detected an unsecured AP.
The AP is attached to your network but is not listed in the
switch security policies. If security policies are enabled,
clients are not granted access to your network through the
unsecured AP.
Green
(flashing)
An air monitor on this port has detected interference. The
interfering device (AP or other radio source) has been
detected by your valid APs, but has no wired presence on
your network.
Amber (solid) Load balancing is enabled on this port or an AP has reached
the maximum number of clients it is configured to support.
Green (solid) All detected APs on this port are operating as expected.
Off No AP is detected on the port (lowest precedence)
