OmniAccess 6000 LC-2G24FP Installation Notes: Installation Guide
6 Part 031659-00 May 2005
Before beginning, read the entire procedure. Make sure you understand all the
precautions in these installation instructions.
Disconnect all cables attached to the line card.
Loosen the module’s fastening screws.
At the front of the Alcatel Wireless LAN Switch, use a #2 Phillips or cross-head
screwdriver to loosen both of the fastening screws on the faceplate of the
installed line card. The screws loosen with counter-clockwise rotation, but are
captive and cannot be fully removed.
Remove the line card.
Grasp the module handle firmly and draw the line card forward from its slot.
There may be moderate resistance as the module comes free from its
connections with the chassis backplane, but do not use excessive force. Once
disengaged from the backplane, the line card should easily slide out the rest of
the way.
Cover blank slots.
For safety considerations, as well as to promote proper airflow for cooling and
to prevent dust from entering the switch chassis, cover any unoccupied slot
with a blank cover plate
CAUTION—If removing a line card from Slot 1, make sure that the
fastening screws for the module in the slot above it are fully secured.
If the module in Slot 3 is loose, it could interfere with the module
removal and possibly damage the components.
