OmniAccess 6000 LC-2G24FP Installation Notes: Installation Guide
4 Part 031659-00 May 2005
2 GBIC ports
The GBIC ports can provide high-bandwidth uplinks between the Alcatel
Wireless LAN Switch and the wired LAN. The Gigabit Ethernet port sockets
accept a variety of Gigabit Interface Converters for versatility in selecting
optical and electrical interfaces. See the installation guide for port and cable
specifications.
Each GE port has its own LNK/ACT LED, located to the right of the port. During
operation, these LEDs provide the following status information:
Inserting a Line Card
The line card is hot-swappable and can be inserted into the Alcatel Wireless
LAN Switch chassis while system power is on or off. However, hot-swapping a
line card is service affecting and traffic processing on this card will stop until
the replacement card is installed and operating.
Make sure you understand the procedure and all precautions.
Before beginning, read the entire procedure. Make sure you understand all the
precautions in these installation instructions.
Prepare the slot.
TABLE 5 GE LNK/ACT LED
Status Description
Off No Ethernet link on the port.
Green An Ethernet link has been established on the port, but no
data is currently being transmitted or received.
Flashing
Green
The port is transmitting or receiving data. The flashing rate is
proportional to your network activity.
Amber The Ethernet link on the port is encountering errors.
6
CAUTION—This procedure should be performed only by a trained
technician.
CAUTION—Be sure to exercise proper Electrostatic Discharge (ESD) pre-
cautions when handling components.
1
2
