31684 Rev. 3.00 September 2004
Builder’s Guide for AMD Athlon™ 64 Processor-
Based Desktops and Workstations
Figure 7. Ensure Proper Contact Between Backplate and Motherboard
Note: The processor socket may be different from the socket pictured in Figure 7, depending on
the version of the AMD Athlon 64 processor being used.
7. Carefully place the retention frame on the motherboard.
8. The screw holes must align with the backplate standoffs. (See Figure 8.)
Figure 8. Retention Frame Screw Holes Aligned with Backplate Standoffs
9. Place the screws and tighten down the retention frame. (See Figure 9 on page 16.)
− Ensure that the retention frame is flat with the motherboard.
− Do not over-tighten the screws.
Chapter 3
Heatsink Installation 15
