32 ASUS A7N266-E User’s Manual
3. HARDWARE SETUP
Connectors
3. H/W SETUP
3) Universal Serial Bus Ports 1 & 2 (Black two 4-pin USB)
Two USB ports are available for connecting USB devices.
4) Parallel Port (Burgundy 25-pin PRINTER)
You can enable the parallel port and choose the IRQ through Onboard Parallel
Port (see 4.4.2 I/O Device Configuration).
NOTE: Serial printers must be connected to the serial port.
Parallel (Printer) Port (25-pin female)
RJ-45
5) Fast Ethernet Port (RJ-45) (Optional)
The RJ-45 connector is located on top of the USB connectors. The USB connector
supplies a direct connection to a local area network (LAN) and is supported by
the onboard LAN controller chipset.
Universal Serial Bus (USB)
