ASUS A7V266-C User’s Manual 15
3. HARDWARE SETUP
3. HARDWARE SETUP
3.2 Layout Contents
Motherboard Settings
1) JEN p. 18 JumperFree Mode Setting (Disable / Enable)
2) SYSCLK p. 19 CPU External Frequency Selection (Switches 1–4)
3) OVER1, OVER2 p. 19 Voltage Over Setting
4) VID1, 2, 3, 4 p. 20 Voltage Regulator Output Volt. Setting (1.675V-1.85 V)
5) KBWK p. 20 Keyboard Power Up (Enable / Disable)
6) USB01_, USB23_PWR p. 21 Two USB Device Wake-ups (+5V / +5VSB)
7) THERMTRIP p. 21 Thermal Sensor CPU Setting (Athlon-Duron / Reserve)
8) CLR_RTC p. 22 Clear RTC RAM (2 pin jumper contact)
Expansion Slots/Sockets
1) DIMM 1/2/3 p. 23 System Memory Support
2) Socket 462 p. 25 CPU Support
3) PCI 1/2/3/4/5 p. 26 32-bit PCI Bus Expansion Slots
4) AGP 4x p. 28 Accelerated Graphics Port Slot
Connectors
1) PS2KBMS p. 29 PS/2 Mouse Port (6 pin female)
2) PS2KBMS p. 29 PS/2 Keyboard Port (6 pin female)
3) USB p. 30 Universal Serial Bus Ports 1 & 2 (Two 4 pin female)
4) PRINTER p. 30 Parallel Port (25 pin female)
5) COM1/COM2 p. 30 Serial Ports (9 pin /10-1 pin male)
6) GAME_AUDIO p. 31 Game/MIDI Port (15 pin female) (Optional)
7) AUDIO p. 31 Audio Connectors (Three 1/8” AUDIO) (Optional)
8) IDELED p. 32 IDE Activity LED (2 pin)
9) FLOPPY p. 32 Floppy Disk Drive Connector (34 pin)
10) PRIMARY / SEC. IDE p. 33 IDE Connectors (Two 40-1 pin)
11) CPU_,PWR_,CHA_FAN p. 34 CPU, Power, and Chassis Fan Connectors (Three 3 pin)
12) USB2_3 p. 35 USB Header (10-1 pin)
13) IR_CON p. 35 Standard Infrared Module Connector (10-2 pin)
14) ATXPWR p. 36 Power Supply Connectors (20-pin block)
15) SMB p. 36 SMBus Connector (5-1 pin)
16) CD/AUX/MODEM p. 37 Internal Audio Connectors (Three 4 pin) (Optional)
17) JTPWR p. 37 Power Supply Thermal Sensor Connector (2 pin)
18)
SPDIF_C
p. 38 Digital audio Interfaces (6-1 pin) (Optional)
19) CHASSIS p. 38 Chassis Intrusion Lead (4-1 pin)
20) LINE_IN p. 39 ASUS Internal Line In Connector (5 pin ) (Optional)
21) BACK_LT/BACK_RT p. 39 ASUS Internal Line Out Con. (Two 2 pin) (Optional)
Layout Contents
3. H/W SETUP
