ASUS A7VL-VM User’s Manual
2. FEATURES
2. FEA TURES
Motherboard Parts
Location
Processor Support Socket A for Socket A AMD Athlon/Duron Processors ........... 3
(NOTE: CPU thermal sensor is integrated on the motherboard,
located near the center of the CPU heat source, just below the
CPU socket)
Feature Setting DIP Switches ................................................... 7
Chipsets VIA VT8364 (VIA ProSavage KL133) system controller ........ 2
VIA VT82C686B PCIset ......................................................... 13
2Mbit Programmable Flash EEPROM ..................................... 9
Main Memory Maximum 1GB support
2 DIMM Sockets ...................................................................... 4
VC133/PC133 memory support
Expansion Slots 3PCI Slots ............................................................................... 18
System I/O 1 Floppy Disk Driver Connector .............................................. 6
2 IDE Connectors (UltraDMA/100 Support) ........................... 5
1 ModemConnector ................................................................ 16
1 Parallel Port Connector ............................................. (Top) 22
1 VGA Connector ................................................... (Bottom) 21
1 Serial COM1 Port Connector .............................. (Bottom) 23
1 Serial COM2 Port Connector ............................................. 13
USB Connectors (Port 0 & Port 1) ........................ (Bottom) 24
USB Connectors (Port 2 & Port 3) ......................................... 11
1 PS/2 Mouse Connector .............................................. (Top) 25
1 PS/2 Keyboard Connector ................................... (Bottom) 25
Audio AC’97 V2.1 Audio Codec ..................................... (optional) 17
Creative Audio Controller ..................................... (optional) 15
1 Game/MIDI Connector (on audio model only)...........(Top) 20
1 Line Out Connector (on audio model only) ........ (Bottom) 20
1 Line In Connector (on audio model only) ........... (Bottom) 20
1 Microphone Connector (on audio model only) ... (Bottom) 20
Network Features Realtek RTL 8139C Fast Ethernet Controller ....... (optional) 19
1 LAN (RJ45) Connector ............................. (optional) (top) 24
Wake-On-LAN Connector...................................................... 14
Wake-On-Ring Connector ...................................................... 10
Hardware Monitoring System Voltage Monitoring (integrated in ASUS ASIC) ......... 9
3 Fan Power and Speed Monitoring Connectors
Power ATX Power Supply Connector ................................................. 1
Others Onboard LED ........................................................................... 8
Form Factor Micro ATX
2.2 Motherboard Components
See opposite page for locations.
