4-28 Chapter 4: BIOS setup
Serial-ATA Conguration
This sub-menu allows you to change Serial ATA settings. Select an item then press
<Enter> to edit.
Select Menu
Item Specic Help
Phoenix-Award BIOS CMOS Setup Utility
Advanced
Serial-ATA Conguration
Serial-ATA Controller [Enabled]
RAID Enabled [Disabled]
x SATA1 RAID Disabled
x SATA2 RAID Disabled
x SATA3 RAID Disabled
x SATA4 RAID Disabled
x SATA5 RAID Disabled
x SATA6 RAID Disabled
Serial-ATA Controller [Enabled]
Allows you to enable or disable the onboard Serial ATA controller.
Conguration options: [Disabled] [Enabled]
RAID Enabled [Disabled]
Enables or disables the onboard RAID controller. When set to [Enabled],
the succeeding items become user-congurable. Conguration options:
[Disabled] [Enabled]
SATA1/2/3/4/5/6 [Disabled]
Enables or disables the RAID function of the rst to sixth SATA master drive.
Conguration options: [Disabled] [Enabled]
HD Audio [Auto]
Allows you to disable or set the High-Denition audio function.
Conguration options: [Auto] [Disabled]
Front Panel Support Type [HD Audio]
Allows you to set the front panel audio connector (AAFP) mode to legacy AC`97
or high-denition audio depending on the audio standard that the front panel audio
module supports. Conguration options: [AC97] [HD Audio]
Onboard 1st/2nd Nvidia LAN [Enabled]
Enables or disables the onboard NVIDIA
®
LAN controller.
Conguration options: [Disabled] [Enabled]
OnBoard LAN Boot ROM [Disabled]
Allows you to enable or disable the onboard LAN boot ROM.
Conguration options: [Enabled] [Disabled]
Silicon SATAII Controller
Allows you to disable or set the function of the extended SATA II controller.
Conguration options: [Disabled] [SATA Mode] [RAID Mode]
