ix
F1A75-V EVO specications summary
(continued on the next page)
APU AMD
®
A- & E2- series accelerated processors with AMD
®
Radeon™ HD 6000 series graphics, up to 4 CPU cores, FM1
package
AMD
®
Turbo Core Technology 2.0 support
DirectX
®
11 Support
* The AMD
®
Turbo Core Technology 2.0 support depends on the
APU types.
** Refer to www.asus.com for the AMD
®
APU support list
Chipset AMD
®
A75 FCH (Hudson D3)
Memory Dual-channel memory architecture
4 x 240-pin DIMM slots support maximum 64GB unbuffered
non-ECC DDR3 1866/1600/1333/1066 MHz memory modules
* The maximum 64GB memory capacity can be supported with
16GB or above DIMMs. ASUS will update the memory QVL
once the DIMMs are available in the market.
** Refer to www.asus.com for the latest Memory QVL (Qualied
Vendors List).
*** When you install a total memory of 4GB capacity or more,
Windows
®
32-bit operating system may only recognize less
than 3GB. We recommend a maximum of 3GB system memory
if you are using a Windows
®
32-bit operating system.
Graphics Integrated AMD
®
Radeon™ HD 6000 series graphics in the LIano
APU
Multi-VGA output support: DisplayPort, HDMI, DVI-D, D-Sub port
- Supports DisplayPort with max. resolution 2560 x 1600 @60Hz
- Supports HDMI with max. resolution up to 1920 x 1200 @60Hz
- Supports single-link DVI with max. resolution up to 1920 x 1200
@60Hz
- Supports D-Sub with max. resolution up to 1920 x 1600 @60Hz
- Supports Microsoft
®
DirectX 11
Supports AMD
®
Dual Graphics
* Refer to www.amd.com for the discrete GPUs that support Dual
Graphics.
Expansion slots 2 x PCIe 2.0 x16 slots (Single @x16 or dual @x8 / x8 mode)
1 x PCIe 2.0 x16 slots (black, max. @x4 mode)
2 x PCIe 2.0 x1 slots
2 x PCI slots
* The PCIe x16_3 slot shares bandwidth with PCIe x1_2 slot.
Due to the CrossFireX
TM
limitation, DO NOT use the PCIe x1_2
slot when you install two CrossreX
TM
graphic cards on both
the PCIe x16_1 and PCIe x16_3 slots to set up a CrossFireX
TM
conguration.
LAN Realtek
®
RTL8111E PCIe Gigabit LAN controller
