ASUS KGPE-D16 4-27
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
Onboard Device Conguration
Serial Port1 Address [3F8/IRQ4]
Serial Port2 Address [2F8/IRQ3]
Onboard 1394 Controller [Enabled]
Onboard LAN1 Chip [Enabled]
Onboard LAN2 Chip [Enabled]
Onboard LAN1 Boot [PXE]
Onboard LAN2 Boot [PXE]
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Allows BIOS to Select
Serial Port1 Base
Addresses.
4.4.3 Onboard Devices Conguration
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Conguration options: [Disabled] [3F8/IRQ4] [3E8/IRQ4] [2E8/IRQ3]
Serial Port2 Address [2F8/IRQ3]
Allows you to select the Serial Port2 base address.
Conguration options: [Disabled] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
Onboard 1394 Controller [Enabled]
Enables or disables the onboard IEEE 1394 controller.
Conguration options: [Disabled] [Enabled]
Onboard LAN1/LAN2 Chip [Enabled]
Enables or disables the onboard LAN1/2 controller.
Conguration options: [Disabled] [Enabled]
The following items appear only when you set
Onboard LAN1/LAN2 Chip
to
[Enabled].
Onboard LAN1/LAN2 Boot [PXE]
Allows you to congure the onboard LAN1/2 boot mode.
Conguration options: [Disabled] [PXE] [iSCSI]
