ASUS M3A78-T
4-15
Block (Multi-sector Transfer) M [Auto]
Enables or disables data multi-sectors transfers. When set to [Auto], the data
transfer from and to the device occurs multiple sectors at a time if the device
supports multi-sector transfer feature. When set to [Disabled], the data transfer
from and to the device occurs one sector at a time.
Conguration options: [Disabled] [Auto]
PIO Mode [Auto]
Selects the PIO mode.
Conguration options: [Auto] [0] [1] [2] [3] [4]
DMA Mode [Auto]
Selects the DMA mode.
|Conguration options: [Auto] [SWDMA0] [SWDMA1] [SWDMA2] [MWDMA0]
[MWDMA1] [MWDMA2] [UDMA0] [UDMA1] [UDMA2] [UDMA3] [UDMA4] [UDMA5]
[UDMA6]
SMART Monitoring [Auto]
Sets the Smart Monitoring, Analysis, and Reporting Technology.
Conguration options: [Auto] [Disabled] [Enabled]
32Bit Data Transfer [Enabled]
Enables or disables 32-bit data transfer.
Conguration options: [Disabled] [Enabled]
4.3.6 Storage Conguration
The Storage Conguration menu allows you to congure your storage device(s).
Select an item then press <Enter> to display the sub-menu.
OnChip SATA Channel [Enabled]
Enables or disables OnChip SATA Channel.
Conguration options: [Disabled] [Enabled]
OnChip SATA Type [IDE]
This item appears only when you set the OnChip SATA Channel item to [Enabled]
and allows you to set the OnChip SATA Type.
Conguration options: [IDE] [RAID] [AHCI]
BIOS SETUP UTILITY
Main
OnChip SATA channel [Enabled]
OnChip SATA Type [IDE]
Options
Disabled
Enabled
