ASUS unique
features
ASUS Dual Intelligent Processors
ASUS EPU
- EPU
ASUS TPU
- Auto Tuning, TurboV
ASUS Power Design
- 4+2 Phase Power Design
ASUS Exclusive Features
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
- ASUS Remote GO!
- ASUS USB 3.0 Boost
- ASUS Network iControl
- Front Panel USB 3.0 Support
- ASUS MemOK!
- ASUS AI Suite II
- ASUS Ai Charger+
ASUS Quiet Thermal Solution
- ASUS Fanless Design: heatsink solution
- ASUS Fan Xpert
ASUS EZ DIY
- ASUS DirectKey
- USB BIOS Flashback with USB BIOS Flashback Wizard for EZ BIOS
download scheduling
- ASUS O.C. Prole
- Precision Tweaker 2
- Multi-language BIOS
- ASUS EZ Flash 2
- ASUS My Logo 2
ASUS Q Design
- ASUS Q-Slot
ASUS exclusive
overclocking
features
Precision Tweaker 2
- vCore: Adjustable CPU voltage at 0.00625V increment
- vDDNB: Adjustable CPU/NB voltage at 0.00625V increment
- vNB: Adjustable NB voltage at 0.00625V increment
- vNB HT Bus: Adjustable HT voltage at 0.00625V increment
- vDRAM Bus: Adjustable DRAM voltage at 0.00625V increment
- vSB: Adjustable SB voltage at 0.00500V increment

- Internal Base Clock tuning from 100MHz up to 600MHz at 1MHz
increment
- PCI Express frequency tuning from 100MHz up to 150MHz at 1MHz
increment
Overclocking Protection:
- ASUS C.P.R (CPU Parameter Recall)

