ASUS P4PE2-X motherboard
1-5
1.5 Motherboard overview
1.5.1 Motherboard layout
PCI1
PANEL
P4PE2-X
®
CD
AUX
Super
I/O
3Mbit
BIOS
Accelerated Graphics Port (AGP)
CPU_FAN
FP_AUDIO
GAME
FLOPPY
PRI_IDE
SEC_IDE
ATX Power Connector
DDR DIMM1 (64 bit,184-pin module)
CHA_FAN
SB_PWR
USB56
CR2032 3V
Lithium Cell
CMOS Power
USBPW34
CLRTC
USBPW56
DDR DIMM2 (64 bit,184-pin module)
USBPW12
Intel
82845PE
MCH
AD1888
PS/2KBMS
T: Mouse
B: Keyboard
USB1
USB2
PARALLEL PORT
SPDIF_O
COM1
USB2.0
T: USB4
B: USB3
Top:
RJ-45
PCI2
PCI3
PCI4
Intel
82801DB
ICH4
ATX12V
RTL
8101L
Below:Mic In
Center:Line Out
Top:Line In
Socket 478
CHASSIS
