When installing, removing or moving the monitor, ensure that
this is carried out by at least 2 people.
Be sure to use a wall-mount bracket designed or designated for
mounting the monitor.
This monitor is designed to be installed on a concrete wall or
pillar. Reinforced work might be necessary for some materials
such as plaster / thin plastic board / wood before starting
installation.
This monitor and bracket must be installed on a wall which
can endure at least 4 times or more the weight of the monitor.
Install by the most suitable method for the material and the
structure.
To attach a VESA-compliant mounting bracket, use M6 screws
that are 5/16 inch (8 mm) to 3/8 inch (10 mm) longer than the
thickness of the mounting bracket.
Do not use an impact driver.
When moving the monitor, be sure to hold it with the unit
bottom and the side of unit. Do not hold the LCD panel or
corners. This may cause product damage, failure, or injury.
Do not use any screw holes other than VESA holes for
installation.
Mounting Precautions
(For ASUS dealers and service engineers)
n
Removing the attachment plate
The attachment plate is only for use with the monitor.
Do not use with any other devices.
1. Spread a thick, soft cloth (blanket, etc.) that will prevent
damage to the LCD panel on a stable at surface where the
entire monitor can be placed, and place the monitor with
the LCD panel face down on the cloth.
2. Remove the screws(x4) that fasten the attachment plate,
and remove the attachment plate.
n
Toppling prevention
To reduce the risk of injury and damage caused by the product
toppling or falling in an earthquake or similar situation, take
measures to prevent toppling and falling.
If the wall or platform on which the monitor is installed is not
suciently strong, the eectiveness of the toppling/falling
prevention measures will be severely compromised. Reinforce
the wall or platform as needed.
The toppling/falling prevention measures are intended
to reduce the risk of injury and damage in an earthquake,
however, the eectiveness of the measures is not guaranteed
in all earthquakes.
Before implementing the toppling prevention measures,
complete all connections.
Secure to wall or post
1. Attach a commercially available eye bolt (a bolt shaped to
allow attachment of a string or cord) to the wall or post.
Verify that the eye bolt is attached rmly and does not come
out.
Commercially available eye bolt
(bolt shaped to allow attachment of
a string or cord)
7RSRIPRQLWRU
2. Run a commercially available cord of sucient strength
through the cable clamp attachments and the eye of the eye
bolt on the wall or post to secure the monitor.
7RSRIPRQLWRU
Commercially
available cord
%DFNRIPRQLWRU
CAUTION!
CAUTION!
