xii
Internal I/O connectors
1 x USB 3.0/2.0 connector supports additional 2 USB 3.0/2.0 ports
(19-pin; moss green)
2 x USB 2.0/1.1 connectors support additional 4 USB 2.0/1.1 ports
6 x SATA 6Gb/s connectors (brown)
1 x CPU Fan connector (4-pin moss green) for both 4-pin (PWM
mode) and 3-pin (DC mode) CPU coolers control with auto
detection support
1 x CPU OPT Fan connector (4-pin Black) for both 4-pin(PWM
mode) and 3-pin(DC mode) CPU coolers control
4 x Chassis Fan connectors (4-pin Black) for both 4-pin(PWM
mode) and 3-pin(DC mode) CPU coolers control
2 x Assistant Fan connectors (1 x 3-pin, 1 x 4-pin [White])
1 x Front panel audio connector(AAFP)
1 x 24-pin EATX Power connector
1 x 8-pin EATX 12V Power connector
1 x System Panel (Q-Connector)
1 x USB BIOS Flashback button
1 x MemOK! Button
1 x DRCT(DirectKey) header
3 x T_Sensor (Thermal Sensor) headers
1 x S/PDIF Out header
1 x TPM header
1 x Clear CMOS jumper
BIOS features
64 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 2.7, ACPI 5.0,
Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS
3, My Favorites, Quick Note, Last Modied Log, F12 PrintScreen
function, F3 Shortcut functions, and ASUS DRAM SPD (Serial
Presence Detect) memory information
Manageability
Wfm 2.0, DMI 2.7, WOL by PME, PXE
Operating System
Support
Windows
®
8.1
Windows
®
8
Windows
®
7
GRYPHON Z97 ARMOR EDITION specifications summary
(continued on the next page)
