2.3 The Front LEDs
LED Description
1 PPP : Steady glow when there is a PPPoA / PPPoE connection.
2 ADSL:
Lights when successfully connected to an ADSL DSLAM
(linesync).
3
LAN Port
1-4:
Steady glow when connected to an Ethernet device.
Glows green for 100Mbps; Orange for 10Mbps.
Blinking light when data is Transmitted / Received.
4 WLAN:
Lit green when the wireless connection is established.
Flashes when sending/receiving data.
5 SYS : Lights when the system is ready.
6 PWR : Lights when the power is ON.
