10 Compact T1 - Release 6.1
Quick Start
Compliant Installation
Ferrite Beads
To be compliant with Part 15A of the FCC and for NEBS compliant facilities, the
following beads are included with each chassis, as well as additional ferrite bead(s)
with the Service cards listed below.
Ferrite Beads shipped with Adit chassis:
Service Card Cables that Require Additional Ferrite Beads:
For additional information on Ferrite beads and their installation on the unit, please
contact Customer Support.
Ferrite Provided Intended For
1 large (1) Power (AC or DC) cable
3 small (2) One on each T1 cable
(1) Ethernet (10Base-T) cable
Card Ferrites
Shipped
with Card
Intended For
ISDN BRI 2 large (1) 25-pair Telco cable (ISDN BRI card in slot 1-3 top
telco, 4-6 bottom)
(1) Alarm cable (requires a loop through the bead, see
drawing above)
OCU-DP 1 large Alarm cable (requires a loop through the bead, see
drawing above)
Quad T1 2 large T1 cables from front of Quad T1card
(1 bead can hold 1-4 cables) or,
(2) One on each 25-pair Telco cable
IP Router 1 small Ethernet Cable (from front of card)
CMG Router 1 small Ethernet Cable (from front of card)
