6
Do not connect the Parallel or USB
cable yet.
1
Make sure that the power switch is off.
Connect the AC power cord to the machine.
2
Plug the AC power cord into an AC outlet.
Turn the power switch on.
3
Connect one end of the telephone line cord
to the socket on the machine marked LINE
and the other end to a modular wall socket.
Warning
■ The machine must be fitted with an earthed plug.
■ Since the machine is grounded through the power
outlet, you can protect yourself from potentially
hazardous electrical conditions on the telephone
network by keeping the power cord connected to
your machine when you connect it to a telephone
line. Similarly, you can protect yourself when you
want to move your machine by disconnecting the
telephone line first and then the power cord.
3
Install the Power Cord
and Phone Line
If you are sharing one phone line with an
external telephone, connect it as shown
below.
If you are sharing one phone line with an
external telephone answering machine,
connect it as shown below.
Please set the receive mode to External
TAD if you have an external answering
machine.
For more details, see “Connecting an
external telephone answering device
(TAD)” in the Appendix of the User’s
Guide.
TAD
TAD
Step 1
Setting Up the Machine
