8 Specifications
Compatible printers The CT-S801 series and the CT-S601 series, etc
(CT-S2000/310/300 and other printers are not compatible)
Power supply DC 5V ±5%
Power consumption Approx. 1 W
Hardware CPU: NXP LPC2458
ROM: 512KB CPU internal flash
RAM: 8MBytes SDRAM
Operation panel LED: 4 (2 on panel, 2 on RJ45 connector)
Button: 1 (on panel)
Network I/F Auto-Negotiation (100Base-TX/10Base-T)
Automatic distinguishing of straight/crossover cables (AUTO-MDIX)
Connection to the printer Printer Class
USB 2.0 FULL SPEED (however, currently CT-S801 side is USB 1.1)
IP Version IPv4
Network protocols TCP, UDP, HTTP, ICMP, DHCP
Port number for printing TCP 9100 (initially)
Configuration changes
from the print server
homepage
YES
Interactive communication YES (only when CITIZEN TCP/IP port driver is used)
Firmware upgrade YES (use print server homepage)
External dimensions 80mm (W) × 70mm (D) × 25mm (H) (including protruding connector)
Weight Approx. 75 g
Operating temperature and
humidity ranges
0 to 40°C, 10 to 90%RH (condensation free)
Storage temperature and
humidity ranges
-20 to 90°C, 10 to 91%RH (condensation free)
Safety standard UL, C-UL, FCC Class A, TÜV-Bauart, CE Marking
