Installing the monitor
6. Connect the wiring harness to the monitor, and tuck the excess wiring
harness length carefully out of the way behind the bezel.
7. Gently insert the monitor into the bezel.
Press only on the edges of the monitor, not on the screen. You should hear
a few soft clicks as the monitor locks into place by four spring clips on the
bezel.
NEVER press on the surface of the
screen! Gently press on the edges
of the monitor case. If you find that
you can not insert the monitor
without excessive force, you may
need to check your wire harness
position for interference with the
insertion process. Your may also
need make the opening slightly
larger.
CAUTION !
Spring clips to lock
the monitor on its
position
Bezel
Press edges to fit
monitor into bezel ,
do not press monitor
screen
Monitor
