iMedia Wall Plate Computer & Video Center Crestron IM-WCCV-M
IM-WCCV-M Installation in a Three-Gang Electrical Box
Standard Three-Gang Electrical Box
(shown with end removed)
Ground Wire
Screws (4) #6-32 x 1"
NOTE: To prevent overheating, do not operate this product in an area that exceeds
the environmental temperature range listed in the specifications table. Consideration
must be given if installed in a closed or multi-unit rack assembly, inside a closed
desk, or in a closed podium since the operating ambient temperature of these
environments may be greater than the room ambient. Contact with thermal insulating
materials should be avoided on all sides of the unit.
10 • iMedia Wall Plate Computer & Video Center: IM-WCCV-M Operations & Installation Guide – DOC. 6621A
