Table of video-in/out terminal selections
Mic.
Ext. video signal1
Ext. audio signal1
Mic.
Ext. video signal2
Ext. audio signal2
Mic.
Main camera video signal
Main cameravideo signal
Main cameravideo signal
INTER-
NAL
R
G
B
1
Input
Output signal Video-out terminal
Audio-out terminal
LR
RGB
Monaural
RGB1
Stereo1 (L / R)
Monaural
RGB2
Stereo2 (L / R)
Monaural
Composite
S-VIDEO
R
G
B
2
Note: The Composite-Video Terminal and the S-Video Terminal receive the image from the main camera regardless
of the input selection.
Resolution selection
When the built-in camera/mode button [MAIN/MODE] on the
front operation panel or wireless remote control is pressed, the
resolution of the built-in camera is switched.
If the monitor is not compatible with SXGA, the resolution of the
built-in camera is switched to other in the order of SXGA
XGA SVGA VGA each time the built-in camera/mode
button [MAIN/MODE] is pressed.
Then, the LED of the selected resolution of all 4 LEDs on the
built-in camera/mode button [MAIN/MODE] on the front
operation panel lights up to indicate the selected resolution.
