2-6 Elo Entuitive Touchmonitor User Guide
Video Cable Connection
1 Set the touchmonitor on a solid horizontal surface, such as a table or desk.
2 Connect the female end of the video cable connector to the back of the LCD
monitor, and connect the other end to the back of the computer.
3 Secure the cable to your touchmonitor and computer by tightening the screws
on the connector clockwise.
Video
cable
Video
port
Female 15-pin
video
connector
Connections on underside
Ferrite bead
