2-8 Elo Entuitive Touchmonitor User Guide
Power Cable Connection
1 Depending on where you live, you will use either the European or
US/Canadian power cable. Connect the female end of the power cable to the
Brick power supply.
2 Connect the Brick power supply into the power port on the touchmonitor.
To protect your equipment against risk of damage from electrical surges in the power
line, plug the Brick supply’s power cord into a surge protector, and then connect the
surge protector to a grounded (three-pronged) AC electrical outlet.
Connections on underside
Serial
touchscreen
cable
Brick power supply
Power cable
Brick power cable port
