Rev. A Installation 2-3
UB-E02 Technical Reference Guide
2.5 UB-E02 Installation
CAUTION:
Before installing the UB-E02, be sure to set the DIP switches or Memory switches as shown
in the table below. For other models, please ask your dealer.
*1 TM-U220 has two DIP switch pattern. See TM-U220 Technical Reference Guide for detail.
Be sure to disconnect the power supply of the printer (in addition to turning off the power
switch) .Even when the power switch is turned off, some of the internal circuit board has
electricity. If you install or remove the UB-E02 with the power supply connected, the UB-E02
and the printer may be damaged.
1. Be sure that the power for the printer and host computer is turned off.
2. Install the UB-E02 in the printer.
If an interface circuit board is already installed, remove it and install the UB-E02.
Model Setting
TM-U200 Series DIP SW 2-8: ON
TM-U210 Series DIP SW 2-8: ON
TM-U220 Series (STD) *1 DIP SW2-8: ON
TM-U220 Series (US) *1 DIP SW2-4: ON
TM-U230 Series DIP SW 2-4: ON
TM-U325 Series DIP SW 2-8: ON
TM-U590 Series DIP SW 2-8: ON
TM-U675 Series DIP SW 2-8: ON
TM-T88/T88II/T88III DIP SW 2-8: ON
TM-T90 MSW 1-8: ON
TM-H5000/H5000II DIP SW 2-8: ON
TM-H6000/H6000II DIP SW 2-8: ON
TM-J7000/J7100 MSW 1-8: ON
TM-J7500/J7600 MSW 1-8: ON
TM-J2000/J2100 MSW 1-8: ON
TM-L90 MSW 1-8: ON
