3.1.3 Basic Operations
3.1.3.1 Getting Familiar with the Key Pad and the Voice Prompt
VoIP Client ATA has a stored voice prompt menu for quick browsing and simple configuration.
To enter this voice prompt menu, simple pick up the phone and press the button on the VoIP Client ATA;
or pick up the phone and dial “***”. The following table shows how to use the voice prompt menu to configure the device for
required voice prompts.
Menu Voice Prompt User’s Options
Main Menu “Enter a Menu Option” Enter ‘*’ to next option and “#” back to main menu, or
Dial 01 – 06, 47, 86 or 99 Menu option
01 “Static IP Mode”, or
“Dynamic IP Mode”
Dial ‘9’ to toggle the selection.
If user selects “Static IP Mode”, user will need to configure
the all IP address information through menu 02 to 05. If user
selects “Dynamic IP Mode”, the device will retrieve all IP
address information from DHCP server automatically when
user reboots the device.
02 “IP Address” + IP address The current WAN IP address is announced. Enter 12-digit
new IP address if in Static IP Mode.
03 “Subnet” + IP address Same as Menu option 02
04 “Gateway “ + IP address Same as Menu option 02
05 “DNS Server” + IP address Same as Menu option 02
06 “TFTP Server “ + IP address Same as Menu option 02
TFTP server is used to update the firmware of the device.
47 “Direct IP Calling” When entered, user will be prompted by dial tone, dial the
12-digit IP address to make a direct IP call. (For details, see
“4.2.2 Make a Direct IP Call”.)
86 “No Voice Messages”; or
“Voice Messages Pending”
If there are voice messages, user can dial ‘9’ and dial pre-
configured phone number to retrieve voice message.
99 “RESET” Dial ‘9’ to confirm the RESET; or
Enter MAC address to restore factory
default setting (For detail, see section 8)
“Invalid Entry” Automatically return to Main Menu
Notes:
Once the LED button is pressed, it enters the voice prompt main menu. If the button is pressed
again while it is already in the voice prompt menu state, it will jump to the “Direct IP Calling” option - dial tone
plays in this state.
• “*” shifts down to the next menu option
• “#” returns to the main menu
• “9” functions as the ENTER key in many cases to confirm an option
• All entered digit sequences have known lengths - 2 digits for menu option and 12 digits for IP address.
Once all digits are accumulated, it automatically processes them.
• Key entry cannot be deleted but the phone may prompt error once it is detected
