3.
Remove the memory module (2) by pulling it away from the slot at an angle.
Reverse this procedure to install the memory module.
Heat sink
NOTE: The heat sink spare part kits include replacement thermal material.
Description Spare part number
Processor heat sink 675514-001
Post controller hub heat sink 685662-001
Before removing the heat sink, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 33), and then remove the following components:
a. Solid-state drive connector board cable (see
Solid-state drive on page 35)
b. Card Reader board cable (see
Card Reader board cable on page 37)
c. Top cover (see
Top cover on page 40)
d. WLAN module (see
WLAN module on page 53)
e. Wireless audio module (see
Wireless audio module on page 51)
f.
System board (see
System board on page 57)
Component replacement procedures
61
