Upgradeability
Upgradeable to 2 processors
Future upgradeable to Xeon® Series 5400/5300 Quad-Core processors (Please contact your
regional sales support to determine quad core upgradeability. Some of the earlier shipping models
may not support this upgrade). 5100 Dual-Core models are not upgradeable to the 5200 Dual-
Core processors.
Memory Protection
Advanced ECC, Online Spare and Mirroring
NOTE:
Mirroring requires optional 2nd memory card.
Memory
One of the following
depending on Model
Type
PC2-5300 Fully Buffered DIMMs (DDR2-667) running at 533 MHz with
4:1 interleaving
NOTE:
4-way interleaving requires optional 2nd memory card.
Standard
(Entry Models)
1 GB (2 x 512 MB)
Standard
(Base Models)
2 GB (2 x 1 GB)
Standard
(Performance Models)
4 GB (4 x 1 GB)
Maximum
64 GB (16 x 4 GB with 2 memory cards)
NOTE:
Memory DIMMs in systems with the Front Side Bus (FSB) running at 1333 MHz will run at
667 MHz and in systems with a FSB running at 1066 MHz or 667 MHz the memory DIMMs will run
at 533 MHz.
Network Controller
Two embedded NC373i Multifunction Gigabit Network Adapters with TCP/IP Offload Engine,
including support for Accelerated iSCSI through an optional Licensing Kit
Expansion Slots
Expansion
Slot #
Technology
Width
Connector
Width
*
Bus
Number
**
Form Factor
Notes
1
PCIe
x4 x8
6
Full length,
full height
slot
Reserved for
integrated
RAID
controller
2
PCI-X
(133MHz,
3.3 Volt)
64-bit
Not
applicable
18
Full length,
full height
slot
Shared bus
with slot 3
3
PCI-X
(133MHz,
3.3 Volt)
64-bit
Not
applicable
18
Full length,
full height
slot
Shared bus
with slot 2
4
PCIe
x4 x8
14
Full length,
full height
slot
5
PCIe
x4 x8
11
Full length,
full height
slot
Optional x8 if
PCIE
expander is
installed in
slot 4
QuickSpecs
HP ProLiant ML370 Generation 5
Standard Features
DA - 12478 U.S. QuickSpecs — Version 41 — 1/26/2009
Page 6
