14 Appendix C Specifications
Kingston Technology Company KNS800/WG User’s Guide – Rev.B01
Appendix C Specifications
Fast EtheRx Model KNS500/WG
Compliance:
IEEE 802.3u 100BASE-TX Standard
IEEE802.3i 10BASE-T Standard
IEEE802.3 CSMA/CD Ethernet Standard
Media Interface:
Five (5) auto-negotiating 10/100 Mbps UTP ports
Uplink Port:
UTP port 5
10BASE-T /100BASE-TX:
Auto-Negotiation
Half / Full-duplex mode:
Auto-Negotiation
Diagnostic LEDs:
1 LED for Power Indicator (steady green)
5 100BASE-TX speed detection LEDs(steady green)
5 Link LEDs (steady green) /Activity (flashing green)
5 LEDs for Full-Duplex (steady green) /Collision
(flashing amber)
Switching Approach:
Store-and-Forward
Flow Control:
Half Duplex:
Full Duplex:
Collision-based Backpressure
IEEE 802.3x
MAC Address Support:
Up to 1K MAC addresses
Filtering/Forwarding
Rate (min. packet size 64 bytes):
148,800 packets/second @ 100Mbps
14,880 packets/second @ 10Mbps
Latency (min. packet size 64
bytes)
100Mbps to 100Mbps
≤
9.1
µ
s
10Mbps to 10Mbps
≤
64.6
µ
s
Max Segment Length:
100 meters (328 feet)
Connector Type:
RJ-45, Female
Cable Type:
UTP 26 to 22 AWG
Cable Grade:
100BASE-TX:
10BASE-T:
Category 5 or better
Category 3, 4, 5 or better
Environmental:
Operating Temp.
0°C to 45°C (32°F to 113°F)
Storage Temp.
-20°C to 60°C (-4°F to 140°F)
Relative Humidity
10% to 90% non-condensing
Electrical:
Input Voltage:
120VAC/60Hz or 240VAC/50Hz, ext. power adapter
Output Voltage:
12VDC/1.2A
Power Consumption:
8.0 Watts maximum
Physical:
Dimension (HxWxD):
1.1” x 6.5” x 6.1” (28mm x 165mm x 155mm)
Weight:
2 lbs. (0.9 kg)
Certification
EMI Standards:
FCC Class A, CE CISPR A, C-Tick
EMC Standards:
EN55022, IEC801-2, IEC801-3, IEC801-4
Low Voltage Directive:
EN60950
