Item
# 9071 FRUs FRU# CRU Tier
10 Microprocessor, Core 2 Duo E8300 Processor 2.83GHz 1333MHz FSB 6M L2 65W
(models)
45C7737 N
10 Microprocessor, Core 2 Duo E8200 Processor 2.66GHz 1333MHz FSB 6M L2 65W
(models ACM ACA ACQ ACT ACK ACJ AFU AFF AGU AGF AJS AJD AJY AHC)
45C7738 N
10 Microprocessor, Core2 Duo E8190 Processor 1333/2600MHz 6M L2 65W Non vPro
(models)
45R2568 N
10 Microprocessor, Core 2 Duo E7200 Processor 2.53GHz 1066MHz 3M L2 65W
(models)
45R8337 N
10 Microprocessor, Dual Core E1400 Processor 2.0GHz 800MHz 512K L2 65W
(models)
45R8339 N
10 Microprocessor, Dual Core E1200 Processor 1.6GHz 800MHz 512K (models) 45R8341 N
10 Microprocessor, Core 2 Duo E7300 Processor 2.66GHz 1066MHz FSB 3M L2 65W
M0 Stepping (models)
46R1622 N
10 Microprocessor, Dual Core E1600 Processor 2.4GHz 800MHz 512K L2 65W M0
Stepping Level (models)
46R1655 N
10 Microprocessor, Core 2 Duo E2180 Processor 2.0GHz 800MHz FSB 1M L2 (models) 45C1773 N
11 System board, Lagavulin III - Jupiter AMT(GA) (models A5G A5M A5Q A5V A5K
A5J A4C A6M A1G A2U A2F A8U A8F A8S A8P A8L A8D A8Y A8G A8M A8A
A8Q A8T A8C A8B A8H A8V A8K A8R A8E A8J A9S A9D A9Y AAU ABU ABF
A3C ACM ACA ACQ ACT ACK ACJ ADM ADA ADQ ADT ADK ADJ AEM AEA
AEQ AET AEK AEJ AFU AFF AGU AGF AJS AJD AJY AKS AKD AKY AHC ANU
ANF)
45R5316 N
11 System board, Lagavulin III - Jupiter non AMT(GA) (models) 45R5315 N
11 System board - Jupiter AMT(GA) fixed ODD issue; support 45nm processor
(models A5G A5M A5Q A5V A5K A5J A4C A6M A1G A2U A2F A8U A8F A8S
A8P A8L A8D A8Y A8G A8M A8A A8Q A8T A8C A8B A8H A8V A8K A8R A8E
A8J A9S A9D A9Y AAU ABU ABF A3C ACM ACA ACQ ACT ACK ACJ ADM
ADA ADQ ADT ADK ADJ AEM AEA AEQ AET AEK AEJ AFU AFF AGU AGF
AJS AJD AJY AKS AKD AKY AHC ANU ANF AMM AMA AMQ AMT AMK AMJ
ALG)
46R8690 N
11 System board- Jupiter non AMT(GA) fixed ODD issue ; support 45nm processor
(models)
46R8689 N
12 Memory module, 512 MB PC2-5300 (667MHz) DDR2 SDRAM (models A5G A5M
A5Q A5V A5K A5J AAU)
41X4255 2
12 Memory module, 1 GB PC2-5300 (667MHz) DDR2 SDRAM (models A4C A6M
A1G A2U A2F A7U A7F A8U A8F A8S A8P A8L A8D A8Y A8G A8M A8A A8Q
A8T A8C A8B A8H A8V A8K A8R A8E A8J A9S A9D A9Y ABU ABF A3C ACM
ACA ACQ ACT ACK ACJ ADM ADA ADQ ADT ADK ADJ AEM AEA AEQ AET
AEK AEJ AFU AFF AGU AGF AJS AJD AJY AKS AKD AKY AHC )
41X4256 2
12 Memory module, 2 GB PC2-5300 (667MHz) DDR2 SDRAM (models ANU ANF) 41X4257 2
The FRUs listed in the following table are not illustrated.
9071 FRUs FRU# CRU Tier
Cable, SATA hard disk drive and optical drive (all models) 39K5061 2
Under-desk Mounting Kit (all models) 39M0599 1
Bezel, Ultra-Bay-Enhanced (all models) 89P6804 2
HSS Tray assembly (includes grommet/pins/bracket/ground springs) (all models) 89P6778 2
Chapter 10. FRU lists 367
