operating from the 3.3V rails and the 12V rail provide the necessary
voltages. The following states determine the typical current consumption
of the controller:
State 1: During a hard reset
State 2: During a drive stress test
State 3: While sitting idle at the DOS prompt
The supply voltages are 12V ± 8 percent (from PCI edge connector only)
and 3.3V ± 9 percent (from PCI edge connector only). Table 3. 11 lists
the power supply for the RAID controllers for each of the three states at
the different voltages.
Table 3.11 Power Supply for SAS 9260 RAID Controllers
Note:
+12V is used in the charging circuitry for the battery pack
on the optional iBBU battery-backed daughter card. If the
BBU daughter card is mounted, the following power
consumption figures apply:
During trickle charging of the battery pack: N/A (no
trickle charge for Li-ION)
During fast charging of the battery pack: 230mA in +12V
current
3.3.4.4 Operating and Non-operating Conditions for SAS 9260 RAID Controllers
For the SAS 9260 RAID controllers, the operating (thermal and
atmospheric) conditions are:
Relative humidity range is 5 percent to 90 percent noncondensing
(20 percent to 80 percent noncondensing for the RAID controllers)
Airflow must be at least 200 linear feet per minute (LFPM) to avoid
operating the LSISAS2108 processor above the maximum
ambient temperature
PCI Edge Connector State 1 State 2 State 3
3.3V supply 330mA 330mA 330mA
+12V supply 1.00A 1.81A 1.53A
3.3V auxiliary supply 30mA 30mA 30mA
