-1-14 -
Size 55cm/22" (508mm/20" Viewable Image Size)
Mask type Aperture grille
Gun In-line
Deflection angle 90°
CRT Phosphors Red, Green, Blue EBU (medium short persistence)
Aperture grille pitch 0.24mm
Phosphor pitch 0.25mm
Face Plate G-WARAS
Focusing method Dynamic Beam Forming (DBF)
Video 0.7Vp-p analog RGB
Sync Separate H, V sync., Composite sync., or Sync on Green
Input Connectors DB9-15P X 2
Input Impedance 75Ω (video), 2.2kΩ (sync.)
Function •
Self-powered HUB complying with Universal Serial Bus Specification Rev.1.1
USB Interface •Upstream port/12Mbps
•3 Downstream ports/12Mbps, 1.5 Mbps (500mA max. per each
Downstream port)
SCANNING Horizontal 30 - 121kHz
FREQUENCY Vertical 50 - 160Hz
RESOLUTION (HxV) 2048 dots x 1536 lines Non-Interlaced maximum addressable resolution format at 75Hz
WARM-UP TIME 30 minutes to reach optimum performance level
BRIGHTNESS 100cd/m
2
, standard full white video signal at 9300K (+ 8MPCD)
Horizontal 2.0 µsec (typ.)
Vertical 400 µsec (typ.)
DISPLAY SIZE 396mm x 297mm(typ.) ratio 4:3 (371mm x 297mm(typ.) ratio 5:4)
COLOR 5000K~9300K
POWER SOURCE AC100-120/220-240V±10% 50/60Hz 140W (typ.) (155W (typ.) with USB operation)
OPERATING Temperature 5 35°C
ENVIRONMENT Humidity 10 90%RH (without condensation)
DIMENSIONS (W)19.5inch x (H)19.4inch x (D)18.6inch / (W) 495mm x (H) 493.5mm x (D) 473mm
WEIGHT Approx. 29.7kg (65.5 lbs.)
TILT/SWIVEL Tilt Angle -5° - +10°
BASE Swivel Angle ±90°
Safety UL1950 (UL), CSA C22.2 No.950 (C-UL)
EN60950 (TÜV-GS)
EMC FCC Class-B, DOC Class-B
EN55022 Class-B, VCCI Class-B
EN61000-3-2, EN61000-3-3, EN55024
REGULATIONS X-Ray DHHS, HWC, Röv vom 8.1, 1987
Other CE-Marking, MPR-II/TCO'91
ISO9241-3, ISO9241-7, ISO9241-8 (TÜV-GS)
TCO '99
International E
NERGY STAR Program
Energy 2000 Labeling Award
Guidelines for the Suppression of Harmonics
in Appliances and General-Use Equipment
6
6 SPECIFICATIONS
INPUT SIGNAL
SIGNAL INTERFACE
BLANKING TIME
* This monitor is registered / certified with Model No. NSZ2107STTUW.
