16
Using the wired remote control mode
Connect the included remote control cable to the remote
control's remote jack and "REMOTE IN" jack on the
monitor.
When the cable is connected, the mode automatically
switches to wired remote control.
When the wired remote control mode is used, the remote
control unit can be operated even if no batteries are loaded.
Operating Range
* Use the remote controller within a distance of about 7 m
/ 23ft. from the front of the monitor's remote control sen-
sor and at a horizontal angle of within 30°.
* The remote control operation may not function if the
monitor's remote control sensor is exposed to direct sun-
light or strong artificial light, or if there is an obstacle
between the sensor and the remote control unit.
Note:
Do not connect the wired remote control to the REMOTE
THROUGH OUT jack. If doing so, the remote control
does not work.
Remote Control Cable
To Remote Jack
POWER
ON
POWER
OFF
RGB 1
RGB 2
POSITION / CONTR OL
RGB 3
EXIT
PROCEED
VIDEO
CONTRAST
RGB/VIDEO
BRIGHT
COLOR
VIDEO
TINT
SHARPNESS
VISUAL
NORMAL
RASTER
NORMAL
ID SELECT CLEAR
Approx.
7m/23ft
30˚ 30˚
POWER
ON
POWER
OFF
RGB 1
RGB 2
POSITION / CONTR OL
RGB 3
EXIT
PROCEED
VIDEO
CONTRAST
RGB/VIDEO
BRIGHT
COLOR
VIDEO
TINT
SHARPNESS
VISUAL
NORMAL
RASTER
NORMAL
ID SELECT CLEAR
