33
* To reset the adjustment value, press the VISUAL
NORMAL button before pressing the EXIT button.
* To delete the main menu, press the EXIT button once
more.
Adjustment of the White Balance
This adjusts the white balance of bright images (Gain) and
dark images (Bias).
1. Align the cursor with icon (4)
Icon (4)
2. After selecting COLOR TEMP, align the cursor with
USER and press the PROCEED button.
The cursor is moved left and right with the POSITION
CONTROL
ᮤ
/
ᮣ
buttons.
4. Return to the main menu
EXIT
POSITION / CONTROL
Becomes weaker
Move up
Becomes stronger
Move down
The cursor is moved left and right with the POSITION
CONTROL
ᮤ
/
ᮣ
buttons.
3. Align the cursor with Gain or Bias of the sub menu,
then make the adjustment with the
ᮤ
/
ᮣ
buttons
while watching the screen.
PROCEED
Color temperature adjustment screen
R-GAIN (WHITE LEVEL)
G-GAIN (WHITE LEVEL)
B-GAIN (WHITE LEVEL)
R-BIAS (BLACK LEVEL)
G-BIAS (BLACK LEVEL)
B-BIAS (BLACK LEVEL)
COLOR TEMP
HIGH LOW USER
PRESS 'PROCEED' FOR
GAIN / BIAS
SETTING
COLOR TEMP
