46
Set Selection Screen for Allotting ID Numbers to
Multiple Screens/Each Set
This sets the VIDEO WALL NO. and SET ID NO.
ID Selection Screen
2. Align the cursor with the desired item
ID SELECT
POSITION / CONTROL
Move up
Move down
ID Selection Screen
4. Return to the main menu
The display will go off when the EXIT button is pressed
or when the DISPLAY TIME setting time has elapsed.
3. Set to the desired value
POSITION / CONTROL
VIDEO WALL No.
* The POSITION CONTROL
ᮤ
/
ᮣ
buttons are used to
switch the numbers from 1 through 6.
* A press of the remote control CLEAR button causes
a reset. (Initial value is ALL)
SET ID No.
* The POSITION CONTROL
ᮤ
/
ᮣ
buttons are used to
enter numbers from 1 through 256. Note that entry of
numbers higher than 256 is not possible.
* A press of the remote control CLEAR button causes
a reset. (Initial value is ALL)
Note:
When both ID numbers have been set, the
priority order will be as described below.
VIDEO WALL > SET ID
EXIT
ID SELECT MENU
VIDEO WALL NO
SET NO
: 1
: 256
Numbers go DOWN
Number go UP
1. Press the ID SELECT button of the remote control
This displays the ID selection screen.
* This function prevents multiple sets from being
controlled at the same time when ID numbers have
been set to multiple screens/multiple sets and the
remote control is being used.
* Only sets with ID numbers that have been set with
this menu can be controlled. Note that the ID SELECT
button is valid regardless of the ID.
* This function is also valid when this set is controlled
via the RS-232C connector.
Press the EXIT button twice.
Press the EXIT button once to return to the main menu.
To delete the main menu, press the button once more.
