RACK MOUNTING
Use the accompanying rack mount bracket to mount the IDC-3000 to the
rack.
NOTE: This rack mount bracket is designed for used with EIA standard racks.
1 Remove the four (A) screws from the IDC-3000. 2 Use the screws removed in Step 1 to fasten the supplied rack mount
bracket (B) to the IDC-3000.
A
A
A
B
B
A
V
3 Mount the IDC-3000 to the rack and tighten the screws.
57.15mm
108.0mm
465.1mm
482.6mm
Rack mount bracket
W
