Installation
Wiring Diagram
AC-IN
OUT
IN
RGB1
HIGH 75Ω
RGB2
VIDEOG B H/CS
V
R S-VIDEO
EXTERNAL
CONTROL
Plasma monitor
IBM XGA/SuperVGA/VGA or
Compatibles or Macintosh G3 series
Macintosh or
Compatibles
Document camera VCR, Video copy
stand or Multimedia application
RGBcable (Supplied)
To mini D-SUB 15 Pin input
To R,G,B,H/CS, V inputs
(BNC)
To VIDEO IN inputs
Pin adapter for Macintosh
(not supplied)
RGBcable (Supplied)
To mini D-SUB 15 Pin input
To EXTERNAL CONTROL
(mini D-SUB 15 Pin input)
External equipment
e.g., Personal computer
To RGB3 DVI 29pin
(not supplied)
Personal computer
with a digital
RGB (TMDS) output
HIROYUK AIZASUSUSUSUSSWA
HIROYUK AIZ
Scan Converter
