Information Screen
This permits a check on-screen of the resolution and data
of the signal that is currently being input.
1. Align the cursor with icon (10) on the second page of
the main menu and display the display mode.
* When video input is selected
SOURCE: VIDEO
MODE: NTSC, PAL, SECAM
Note:
NTSCis processed as 4.43 NTSC.
Icon (10)
Information screen
* When RGB input is selected
SOURCE: RGB1, RGB2, RGB3
“NO SIGNAL” is displayed when there is no signal.
H-FREQ: Horizontal frequency (kHz)
V-FREQ: Vertical frequency (Hz)
H-POL: Polarity of the horizontal sync signal
Neg./Pos. (Negative polarity/Positive polarity)
V-Pol.:Polarity of vertical sync
Neg./Pos. (Negative polarity/Positive polarity)
2. Return to the main menu
* Settings cannot be reset.
* To delete the main menu, press the EXIT button once
more.
* The vertical frequency that is displayed in the display
mode can have a slight difference with respect to the
actual vertical frequency of the connected input signal.
Vertical signals of between 60 Hz and 70 Hz have an
error of plus/minus 3 Hz. Vertical signals of 70 Hz or
greater have an error of plus/minus 5 Hz. The
frequency display of the display mode via the OSM
system should always be regarded as a guideline.
EXIT
SOURCE INFO.
RGB1
H-FREQ.
V-FREQ.
H-POL.
V-POL.
31.5kHz
60.0Hz
NEG
POS
SOURCE INFO.
VIDEO
MODE : NTSC
